cnc spring forming machine

Name 10 axis CNC spring forming machine
brand HYD
shaft 10
Wire diameter 0.3-2.5mm
Applicable material Iron, stainless steel, copper alloy
Model HYD-25T-10A
Number of Axes 10 Axes
Wire Diameter 0.3-2.5mm
Wiire Feed Roller 2 Pairs
Max Wire Feed Speed 110m/min
Max Wire Feed Speed ±0.05(Length)
Servo Motor Power 10KW
Reducer 7 Pcs
Decoiler 150KG
Voltage 380V
Machine size 1400*950*1700mm
Machine Weight 900KG

10 axis CNC spring forming machine features:

1. Full servo motor control, easier to operate than CAM drive, saving time.
2. Equipped with free hand, it can move left and right, up and down, and fold fast. When processing more complex products, 8 arms are not enough, and the free hand can make up for it
3. The guide rail adopts Taiwan Silver high precision series, with good rigidity, accurate operation and low noise.
4. The control system interface can be set to the language of the customer’s country, which is convenient for customers to understand and operate.

Reviews

There are no reviews yet.

Be the first to review “cnc spring forming machine”

Your email address will not be published. Required fields are marked *

Unable to find spring machine that meet your needs, please let us know, we support processing customization

Frequently Asked Questions

Yes, our spring machine and bending machine, tempering furnace have CE certificate.

The standard voltage of our machine is 380V, and transformers can be equipped according to different voltages in each country.

Our company has 4 R&D personnel, which can be customized according to your needs.

Different countries have different trading methods, generally FOB and CIF, according to customer requirements to choose.

Our company has 3 full-time after-sales service personnel, professional answer customer feedback questions. We have a one-year warranty for the export of the machine. If there is a problem during the warranty period, we provide free accessories and video guidance for customers to disassemble and assemble. If there is a local agent, the agent will be arranged to go to the scene to guide and solve the problem.

Different models, the number of donated knives is also different, generally 4-10 sets of gifts.
